Our dust blowers are made up of a heavy duty dynamically balanced vaneaxial fan with safety guards on all inlets. The steel impeller is mounted directly to the shaft of the stand-mounted motor. Motors are available from 5 to 25 horsepower, 3 phase electric and have options for magnetic starters and remote control. Single phase electric motors are available for blowers up to 7.5 horsepower.
Magnetic starter included.
| DB-50.1 / DB-50.3 | DB-75.1 / DB-75.3 | DB-100 | DB-150 | DB-200 | DB-250 | |
|---|---|---|---|---|---|---|
|
Horsepower |
5 |
7.5 |
10 |
15 |
20 |
25 |
|
Phase |
Single or Three |
Single or Three |
Three |
Three |
Three |
Three |
|
CFM |
3200 |
4700 |
6350 |
7900 |
8375 |
10350 |
|
Amps @ Voltage |
1PH: 27A @ 220V 3PH: 17A @ 220V |
1PH: 38A @ 220V 3PH: 20A @ 220V |
27A @ 220V |
37A @ 220V |
49A @ 220V |
60A @ 220V |
|
Inlet Size |
10″ |
12″ |
12″ |
14″ |
16″ |
18″ |
|
Outlet Size |
12″ |
14″ |
14″ |
16″ |
18″ |
20″ |
|
Fan RPM |
3450 |
3450 |
3450 |
1725 |
1725 |
1725 |
|
Fan Size |
13″ |
13.5″ |
14″ |
25″ |
26″ |
27″ |
|
Weight |
280 lbs |
330 lbs |
360 lbs |
750 lbs |
810 lbs |
850 lbs |
